RGH Series
LED Floor Tile Panel

The RGH Series LED floor tile screen series, as a digital floor display product, adopts a sturdy and durable die-casting composite structure and a resin mask with high wear resistance, so that it can be directly stepped on when placed on the ground. It adopts an overall closed design and has obtained IP68 protection grade certification. The modular design of quick disassembly and assembly makes installation and maintenance easy. The product is combined with virtual software technology and interactive software technology in the application, which can have extremely powerful application functions and create extraordinary and excellent simulation effects.

LED Floor Tile Panel
LED Floor Tile Panel
LED Floor Tile Panel
LED Floor Tile Panel
LED Floor Tile Panel

Features of RGH Series Creative LED Screen

  • It adopts cabinet-type design, which is convenient to disassemble, reliable, and easy to maintain; it is used in various large-scale entertainment venues and large-scale events;

  • The RGB lamp beads are used to encapsulate, arranged in sequence and evenly distributed on the unit board to form a display screen;

  • Good uniformity, excellent luminous consistency, and excellent effect;

  • Display any content that can be displayed on the computer, such as TV, DVD, animation, etc., with manual and automatic brightness adjustment, multi-screen segmentation and other editing functions;

  • Variety of colors, 256-level grayscale, brightness up to 7000CD or more; richer and brighter colors! High stability (no jitter, flicker, loose connectors);

  • Real music control, through the microphone, you can control the changes of the LED color display wall according to the live music played by the DJ, and realize the seamless connection with the music, so that the sound and light can be integrated;

  • It is suitable for TV studios, grand theatres, large entertainment venues and stage backgrounds for outdoor performances at night. The specifications can also be customized according to user needs.


RGH Series Creative LED Screen Specifications

Items

Parameters

Model Number

P3.91-13S

LED Beads

KingLight

Pixel Pitch

3.91mm

Module Size

250mm*250mm

Module Resolution

64dots(W)*64 dots(H)

Cabinet Size

500*500mm

Cabinet Resolution

128*128dots

Mesh Material

Acrylic

Cabinet Material

Die-Casting Aluminum

Pixels Density

65536 dots/m2

Pixel Configuration

1R1G1B

Package Mode

SMD1921

Drive Type

Constant drive (2038S/MBI5124)

Scan

1/13 scan

Refresh Rate

1920Hz

Port Type

HUB75

Brightness of White Balance

≥7500cd/m2

View Angle

160°

Best View Distance

4-50m

Display Colors

687milllion

Power Consumption

300w

Net Weight

9kg

Protection level

IP65
