RMD Series
Thin LED Display

Name: RCM Series
Brand: Shenzhen Raymai Industrial Group Co., Ltd.

Raymai Mini LED has the characteristics of ultra-thin, ultra-light, seamless, ultra-high-definition 4K display, 3840HZ ultra-high refresh rate, etc., and has upgraded the LED chip package in the new generation of small-pitch Mini LED screen, at P0.9375/P1.25 /P1.56/P1.875 adopts COB integrated package, which can pass mass transfer technology, combined with self-developed optical film technology, so that pixel points can be imaged independently, while realizing LED display surface light source, it is not easy to cross light, and can overheat treatment technology to make life longer.

Features of RMD Series Thin LED Display

Full pre-maintenance
Ultra-thin (thickness only 48mm)
Ultra light (weight only 7.0KG)
Extremely fast installation
High Definition, 4K Ultra HD
Seamless stitching
High refresh rate

RMD Series Thin LED Display Specifications

Item	RM-SM-0.937	RM-SM-1.25	RM-SM-1.56	RM-SM-1.875
Pixel Pitch	0.937mm	1.25mm	1.56mm	1.875mm
LED Configuration	Four-in-one Gold Wire	SMD1010	SMD1010	SMD1515
Pixel Density	1137777dot/m2	640000dot/m2	409800dot/m2	284444dot/m2
Module Size	150X168.75mm	150X168.75mm	150X168.75mm	150X168.75mm
Module Resolution	160X180dot	160X180dot	96X108dot	80X90dot
Cabinet Size	600X337.5mm	600X337.5mm	600X337.5mm	600X337.5mm
Cabinet Resolution	640X360dot	480X270dot	384X216dot	320X180dot
Scan Mode	64S	45S	54S	45S
Driving IC	ICN2069/MBI5754	ICN2065/MBI5264
Max.Power Consumption	800W/m²
Ave. Power Consumption	260W/m²
Gray Scale	16bit
Cabinet Weight	4.5kg/Panel
Brightness	600CD/m2
Viewing Angle (H/V)	140°/140°
Refresh Rate	3840HZ
Environment	INDOOR
Control Mode	Synchronous display with control PC by DVI
Support Input	Composite,S-Vido,Component,VGA,DVI,HDMI,HD_SDI
Operation Power	AC110~ 240V, 50/60Hz
Operating Temperature	- 20°C~60°C
Operating Humidity	10%~90%
Operating Life	≥100,000hours
Maintenance	Front Service
